Description
why you will love it
- Built with TORAY T700 Carbon Fiber 20″ Foldable Frame and Fork
- Equipped with 9s SHIMANO SORA R3000 Shifter & Derailleur
- SHIMANO MT200 Hydraulic Disc Braking System
- 20″ Wheel and Tire
- Foldable frame, stem, and pedals – Fold Size 80 x 64 x 40 cm
- Adjustable seat post and stem
20 Inch SAVA Z1 9S carbon folding bike
Features
Lightweight T700 carbon fiber frame+fork
Lightweight,durable and strong strength
Carbon fiber hardness test
Durable ,strong rigid and good shock absorption
Hidden folding box
The hidden folding box patented design makes the folding bike stylish looking.
Adjustable seat post and stem
Adjustable to your comfortable riding height,and it is suitable for adults and children.
Shimano sora R3000 groupset
Exquisite workmanship,detailed presentation,only for high-end
Lightweight Hollow Prowheel Crankset
The hollow design helps to improve the rigidity of cross-legs while reducing weight
Hydraulic disc brake
sensitive braking ,safe braking,stop immediately
20inch folding bike wheels
Smaller wheels allow for a smaller fold
Only need 3 steps to fold
Easy to fold,quick release
Mini folded size
saving space, more convenient to travel, easy storage in car trunk
Unpacking and Assembly
Easy to assemble
Specs
Model
|
Z1 9S 20" Carbon Fiber Folding Bike
|
Wheel Size
|
20 inch
|
Color
|
Black Red, Black Blue, Black Orange
|
Weight
|
10kg/22.05lb (not including package)
|
Frame
|
Toray T700 carbon fiber
|
Fork
|
carbon fiber, disc fork
|
Handlebar
|
560*25.4*9 degree
|
Head parts
|
1-1/8" 28.6*41.8*52*39.8mm
|
Stem
|
Folding head tube, double, stem: 300MM, w/o teeth; Bend: 10 degree
|
Shift lever
|
SHIMANO SL-R 3000, SORA, right lever 9s
|
Rear Derailleur
|
SHIMANO RD3000, SORA GS 9-SPEED
|
Brakes
|
SHIMANO M315 oil brake, F/R1000 R/L1700/ TEKTRO M275 Hydraulic disc brake (Randomly send)
|
Freewheel
|
R42-9 11-32T 9S CP
|
Chainwheel
|
Prowheel 53T*170 9S
|
Chain
|
KMC brown
|
Seat post:
|
Sand BK, water drop type 580mm (Adjustable)
|
Pedals
|
Folding Pedals |
Rim
|
Aluminium 20*24H*14G
|
Hub
|
Two bearings, 14G*24H, straight hub, w/quick release
|
Tires
|
CST, black 20*1.75
|
Accessories
|
Multi Assemble tools, User Manual
|
Max User Weight: 220 lbs
The standard brake is set to control the front brake with the left hand and the rear brake with the right hand, please let us know if you want to change it.
Sizing
Recommend height: 148cm-180cm (4'10'' - 5'11'')
