- Price
- Weight
- Shifters
- Front Derailleur
- Rear Derailleur
- Crankset
- Brakes
- Frame
- Fork
- Wheelset
- Handlebar
-
$2,999.00
- About 7.72kg(17lbs)
- Shimano Ultegra Di2 R8170
- Shimano Ultegra Di2 R8150
- Shimano Ultegra Di2 R8150
- Shimane Ultegra R8100
- Shimano Ultegra R8170
- T800 Carbon fiber reinforced frame(CFR)
- T800 Carbon fiber
- T800 Carbon fiber
- T800 Carbon fiber
T800+T1000 Carbon Fiber Reinforced Frame
This frame,blending T800 and T1000 carbon fibers, fuses durability and agility. T800 provides tensile strength as the backbone, while T1000—among the strongest carbon fibers—adds targeted reinforcement at high-stress zones for max impact resistance without extra weight. It offers responsive, robust rides, lighter than traditional alloys yet built to endure tough conditions.
Ultra-Rigid Carbon Fiber Fork
Made of high-modulus carbon fiber, offers unmatched steering precision and vibration damping. Lightweight to ease climbs, it’s stiff for instant responsiveness in corners or technical terrain, absorbing rough-surface shocks for a smooth, controlled ride. Complementing the frame, it blends strength and finesse for precise turns.
Carbon Fiber Wheels
These carbon fiber wheels slice through air with minimal resistance, converting pedal strokes into forward momentum. Lightweight to reduce rotational mass, they enable quicker acceleration and sustained high speeds—great for sprints and long rides. Reinforced rims handle varied loads and roads, offering strong lateral stiffness for stable handling even at top speeds, boosting performance for racing or personal bests.
Integrated Carbon Handlebar
This integrated carbon fiber handlebar-stem unit cuts wind resistance by eliminating traditional joints, boosting speed. Its ergonomic design reduces hand fatigue with multiple grip positions for varied terrain, while being ultra-lightweight yet stiff—ensuring precise steering and control. A definitive upgrade for riders demanding aerodynamics, comfort, and performance.
Customize Your Ride: W45 Wave Carbon Wheels & B60 BORA WTO 60 DB Wheel
UCI & CE Certified: Race-Ready Performance
Engineered to meet strict UCI racing standards and CE safety certifications, this component ensures compliance for competitive events while guaranteeing reliable, regulation-approved performance for both racing and everyday riding.
Specifications
| Model | 2025 SAVA Blade SLR8 W45/B60(R23-R8170-24S) |
| Weight | About 7.72kg(17lbs) Varies by size |
| Frame size | 45cm, 48cm, 50cm, 52cm, 54cm |
| Color | Blue, Red, Green |
| Frame | R23, Carbon fiber (CFR) |
| Fork | R23, Carbon fiber |
| Seat post | Carbon fiber, shaped 350MM |
| Rear Derailleur | SHIMANO Ultegra RD-R8150, 12-SPEED |
| Front Derailleur | SHIMANO Ultegra FD-R8150, 12-SPEED, CS-ANGLE: 61-66, GEAR: 50-54T, CL: 43.5MM |
| Crankset | SHIMANO Ultegra FC-R8100, 12-SPEED, 2, 170MM, 50-34T |
| Cassette | SHIMANO Ultegra CS-R8101, 12-SPEED, 11-12-13-14-15-17-19-21-24-27-30-34T |
| Shifters | SHIMANO Ultegra ST-R8170 |
| Brakes | SHIMANO Ultegra BR-R8170, Hydraulic disc brake |
| Chain | SHIMANO CN-M8100, 110 L, 12-SPEED |
| Wheels | Carbon Fiber, (W45 wave wheels and B60 BORA WTO 60 DB Optional) |
| Rotors | SHIMANO RT-CL800, SS 140MM |
| Tires | 700 x 28C Continental Tires |
| Handlebar | Carbon fiber, integrated, 380*90 |
| Saddle | Fizik saddle |
| Pedals | Bearing Pedals 9/16 (free include) |
| Note | The standard brake is set to control the front brake with the left hand and the rear brake with the right hand, please let us know if you want to change it. |
Size & Geometry
Note: Size recommendations are for reference only. Please refer to the frame geometry chart below for detailed measurements.
Frame Geometry Chart

| Parameter | 450(XS) | 480(S) | 500(M) | 520(L) | 540(XL) |
|---|---|---|---|---|---|
| Recommend Height | 153 - 168cm | 165 - 175cm | 173 - 183cm | 180 - 190cm | Above 190cm |
| A Seat Tube (mm) | 450 | 480 | 500 | 520 | 540 |
| B Top Tube (mm) | 505.77 | 522.4 | 539 | 555.6 | 572.9 |
| C BB Drop(mm) | 70 | 70 | 70 | 70 | 70 |
| D Chainstay(mm) | 405 | 405 | 405 | 405 | 405 |
| E Scat Angle (°) | 75.4° | 74.8° | 74.2° | 73.6° | 73° |
| F Head Angle(°) | 71° | 71.9° | 72.5° | 72.9° | 72.9° |
| G Front Center(mm) | 580.76 | 579.9 | 585.8 | 592.7 | 603.6 |
| H Head Tube Length (mm) | 100 | 118 | 136 | 154 | 173 |
| I Fork Offset(mm) | 49 | 49 | 45 | 45 | 45 |
| J Reach (mm) | 375.55 | 380.78 | 386.36 | 391.32 | 396.72 |
| K Stack (mm) | 499.95 | 521.37 | 539.69 | 558.24 | 576.40 |
| L Frok Lenght(mm) | 370.6 | 370.6 | 370.6 | 370.6 | 370.6 |
| M Wheelbas (mm) | 974.32 | 974.6 | 980.5 | 987.5 | 998.5 |
| N Standover(mm) | 734 | 756 | 778.76 | 794.92 | 813.43 |
Notice: The recommended size is for reference only. Please determine the size that suits you based on the frame geometry.
Service & Support
Product Manuals
Installation Videos
Installation Video
SAVA Blade SLR8-Ultegra Di2 Full Carbon Road Bike 24SP
Pink / 45cm(XS) / Wave Pattern(W45)
